PRODUCT FEATURES
Our multi-louvred ventilator that provides a cost effective, non-powered solution for removing large volumes of warm air/ or smoke from a building quickly and effectively.
Developed as an advancement of the proven Ventra system, it addresses increasing global demands for improved airtightness and thermal insulation in modern building designs. The unit is suitable for fresh air supply via facade, smoke and air extracting through facade or roof installation and can also support natural daylighting.
Manufactured to ISO 9001 quality standards, the ventilator is constructed from high-quality, corrosion-resistant aluminium to promote durability, water tightness and low maintenance. Opening options include pneumatic cylinders, electric motors or a combined system offering flexibility across a wide range of applications.
TYPICAL APPLICATIONS
Suitable for installation on both roofs and facades, with adjustable installation angles from 0 degrees to 90 degrees. Commonly used in industrial buildings, warehouses, logistics centres, shopping centres, atriums, schools, stairwells and similar environments.
.jpg)
MATERIALS
Constructed from tempered aluminium that is resistant to seawater and corrosion (EN AQ 5754) and fitted with corrosion-resistant bearings. Each unit includes an integrated weather seal and a hydrophobic tape for enhanced protection. Aluminium is supplied untreated as standard, with the option for electrostatic powder coating in any RAL colour.
DIMENSIONS
Roof opening widths range from 300mm to 2400mm, while opening lengths span 746mm to 3826mm (up to 17 louvres maximum).
Our units are available in large sizes, with dimensions up to 2400 x 3826mm (width x length).
REGULATIONS
The systems has been tested and is certified in accordance with EN 12101-2.
WEIGHT
Depends on the dimensions and type of infill.
OPTIONS
Custom dimensions, Powder-coated design (any RAL colour), Bird or insect mesh, Anti-fall grid 1200 J.
OPENING ANGLE
Individually adjustable, allowing opening position from 0 degrees up to 90 degrees.
CONTROLS NATURAL VENTILATION
P1: Single pipe compressed air opertion
P2: Double pipe compressed air operation
M230V: Electric motor
Combination Set: P1 + 230 V or P2 + 230 V
CONTROLS FIRE VENTILATION
P1: Single pipe compressed air opertion with fire function
P2: Double pipe compressed air operation with fire function
M24V: Electric motor
